Product Description
* PLEASE NOTE: THIS ITEM HAS BEEN DISCONITINUED BY THE MANUFACTURER. *
- This item is available from the manufacturer and can be pre-ordered. Please call us for more details.
For modern craftsmen who strive for perfection with each project, the Powermatic CNC line is the premium choice. The extruded aluminum table delivers a large, sturdy surface while the integrated T-slots allow the hold-down clamps to be positioned in any location. The handheld controller attaches to the DSP control box via an 8-foot cable that makes it easy to oversee any project from a variety of positions. The included touch-off puck allows you to quickly and easily re-zero your Z-axis with the push of a button on your controller. The unparalleled design of these machines will give you the confidence, flexibility and durability needed to make even your biggest dream project a reality.
Features:- Enclosed cabinet is heavy-duty welded steel and includes a handy toolbox for storage
- Exclusive gravity cast aluminum gantry supports provide greater stability of the spindle
- Flexible nylon track chains protect all cables preventing rubbing and stress
- High-torque stepper motors control each axis, providing fast, quiet and precise movement
- Hold down clamps have a 5/16" T-bolt with a 1-1/8" wide by 5-1/4" aluminum arm - 4 hold down clamps included with CNC kit
- Included dust shoe provides a clean surface as the machine works when hooked up to a dust collector
- Integrated casters provide mobility, while independent leveling feet provide stability
- Linear guideways with recirculating ball bearings ensure precise and accurate positioning of the tool bit
- Precision ball screws with recirculating ball bearings allow for rapid movement on each axis while maintaining precise spindle placement
- MDF spoil board protects the table from damage and can be quickly resurfaced using the pre-loaded program
- Spindle Speed (RPM) = 0 – 24000
- Style (Type) = CNC
- X-Axis Travel (In.) = 24
- Y-Axis Travel (In.) = 48
- Z-Axis Travel (In.) = 6
- Rapid Feed Rate (IPM) = 200
- Weight (Lbs.) = 748
- Motor Power (HP) = 3
- Floor Space Required (In.) = 52 x 69
- Dust Collection Minimum CFM Required (CFM) = 300
- Motor Phase = 1
- Motor Voltage (V.) = 230
- Prewired Voltage (V.) = 230
- Recommended Circuit Size (Amps.) = 10
- Height = 0.0000
- Length = 0.0000
- Width = 0.0000
- Weight = 750.0000
- Weight (Lbs.) = 748
- Width = 0.0000
- Weight = 750.0
- Height = 0.0000
- Length = 0.0000
- Find out more about our JPW Shipping Policy Here
The Woodturning Store is proud to be an authorized Powermatic dealer. Powermatic is an iconic brand of woodworking machinery, getting its start in 1921 in McMinnville, Tennessee and today is a part of JPW Industries, a world leader in tools and machinery for hobbyists, schools and industry. We are a full line dealer for Powermatic, Jet Tools and Wiltons brands and can offer every single product in their lines. Contact us with any questions you may have. We are always happy to help you making the best selection for your needs.
